FW1-025GM011 FW1-025GP011

FW1-025GM011 is stainless steel body, G1" female thread; Measure range is 1-11l/min.

FW1-025GP011 is POM Plastic body, G1" female thread; Measure range is 1-11l/min.

This products is produced by ourself factory, brand is A.YITE, we could supply a very competitive price. We could supply a customized service for different size or connection.

Technology data:

Connection: Internal thread, G1"
Contact rating: max 0,5 A
Contact rating: max 50 VA
Electrical connection: M12x1, 4-pole
Flow max: 60 l/min
Flow range: max 11 l/min
Flow range: min 1 l/min
IP class:  IP67
Material of body: POM or SS304
Material spring: Stainless steel 301
Pressure drop: 0.8 bar at maximum flow
Pressure range: max 100 bar or 10bar for plastic body
Temperature of media to 90C
Voltage: AC max 230 V
